Mono-Wall® Internal Wall System
Panels are manufactured in Australia and offer a simple alternative to conventional stud and plasterboard walls.
Environmentally friendly, recyclable and often reusable, this is the smartest way to build internal walls. Strong, relatively lightweight and easy to install. Nothing for White Ants to eat and fully insulated, with savings that are hard to ignore.
- MWIN70 Panel Specifications
- R1.5 insulation, 50mm polystyrene core.
- Wall finish 10mm plasterboard each side. (sheet/panel sizes as ordered)
- Steel track 50mm x 27mm .75BMT AS1397.21
- Note: All panels can be ordered with or without electrical channels at 600 centres.
- MWIN90 Specifications
- R1.8 insulation, 70mm polystyrene core.
- Wall finish 10mm plasterboard to both sides.
- MWSD70 Sound Wall Spec's
- R1.5 insulation, 50mm polystyrene core.
- Sound deadening plasterboard to both wall faces.
- MWFR70 Fire resistant wall
- R1.5 insulation, 50mm polystyrene core.
- Firechek® plasterboard to both wall faces.
Wall Facings:
Most plasterboard linings and sizes are available on request. (Conditions Apply)
NOTE: Due to Mono-Walls® continuing product development programme, product specifications while correct at the time of printing, may change at any time.
Request for an installation manual.
Monowall Internal Wall Panel Prices.
| Product Code | Description | RRP Price | |
| INT702412 | Plasterboard wall 2400high x 1200wide x 70mm thick | Panels | $229-00 |
| INT702712 | Plasterboard wall 2700high x 1200wide x 70mm thick | Panels | $258-00 |
| INT703012 | Plasterboard wall 3000high x 1200wide x 70mm thick | Panels | $287-00 |
| INT701812 | Plasterboard wall 1800high x 1200 wide x 70mm thick | Panels | $172-00 |
| INT701512 | Plasterboard wall 1500high x 1200wide x 70mm thick | Panels | $145-00 |
| D8202040 | Extra for Pre-hung Door, RH hinged 820Door AO | Plus. Add to panel cost. | $249-00 |
| D8202040 | Extra for pre-hung Door, LH hinged 820 Door AO | Plus. Add to panel cost. | $249-00 |
|
|
|
|
|
| Walls 90mm | Thick with 10mm | Plaster finish | RRP |
| INT902412 | Plasterboard wall 2400high x 1200wide x 90mm thick | Panels | $253-00 |
| INT902712 | Plasterboard wall 2700high x 1200wide x 90mm thick | Panels | $285-00 |
| INT903012 | Plasterboard wall 3000high x 1200wide x 90mm thick | Panels | $318-00 |
|
|
|
|
|
| INT70T | Floor Track 50 | Per Meter | $13-50 |
| INT70J | Panel Joiners 250 | Each | $ 5-50 |
| INT90T | Floor Track 70 | Per Meter | $11-80 |
| INT90J | Panel Joiners 250 | Each | $ 6-20 |
Main Features
- Termite resistant
- Fully insulated
- Energy efficient
- Thin wall technology to gain more space
- Fire resistant
- Earthquick resistant
- Rapid constuction
- Cost Effective
- Optional finishes
