Mono-Wall® Pre-made Walls & Pricing
- 70mm Plasterboard Wall Panels
- 90mm Plasterboard Wall Panels
Specifications:
Wall finish 10mm plasterboard finish, AS2588, AS3837 with Zero fire spread and insect repellent 50mm or 70mm M grade polystyrene core.
Add On Services:
- Electrical channel at 600 Centres.
- Plumbing to order.
Panel Weight:
- 70mm 12 kg/m2 eg. 2.4 x 1.2 x .70 = (34.6kg per panel).
- 90mm 12.4 kg/m2
Compliance: AS1366.3, AS2588, AS3837 BCA Clause C1.12
Acoustic Standard AS119. Rw 27 Ctr -3
Thermal Insulation:
- 70mm Wall R1.5
- 90mm Wall R1.8
Dementions:
- INT70 Standard PB 2400H / 2700H x 1200W x 70mm Thick.
- INT90 Standard PB 2400H / 2700H x 1200W x 90mm Thick.
- INTD70/90 Door Panel with pre-hung Readicote 720, 770 or 820 x 2040 Door in 2400mm x 1200W x 70 or 90mm Thick Panel.
Gal Steel Floor Track: 50/70mm x 25mm x .75 BMT AS1397 / Aluminium Track 50 x 25 x 3mm
Price Each:
- INT70mm 2.4 x 1.2 Panel $195.30
- INT70mm 2.7 x 1.2 Panel $219.45
- INT90mm 2.4 x 1.2 Panel $220.50
- INT90mm 2.7 x 1.2 Panel $242.55
- INTD70. Pre-hung door 2400 Panel $403.20
- INTD70. Pre-hung door 2700 Panel $427.35
- INTD90. Pre-hung door 2400 Panel $430.50
- INTD90. Pre-hung door 2700 Panel $452.55
Floor Track 50/70mm $13.50 per LM
